Pharmaceutical Machinery

The coating pan is a conventional system for film / sugar coating of tablets, capsules, peppermints, food products and similar other products. Salient Features:
* Pear shaped design facilitates in complete coating of the product.
* Optionally provided with baffles inside the pan for reversing of the tablets.
* Faster drying due to hot air blower.
more...

For mixing & grinding, electrically operated having capacity of few gms to 1 KG & 2 KG. Fitted with geared motor with max speed of 80 rpm. The jar is made of SS and having steel balls of different sizes to be put in jar for mixing & grinding pesticides power. Jar is interchangeable and easily removable, light in weight and compact unit working on 220 V AC with 1 KG cap. 1.)  SS Drum 2 KG capacity. 2.)  Aluminum Drum 1 Kg Capacity. 3.)  Aluminum drum 2 KG capacity. more...

SS 316 High polished vessel with high speed shearing agitator for exothermic reaction in pharmaceutical industry.

* CGmp model with SS316 contact parts. Single piece design with automatic shaking system.
* AHU system for inlet air with heap filtration.
* Fully automatic control panel with PLC.
* Capacities available from 1kg R & D model to 1000kg/ batch Spraying system option available for top spraying.
more...

We are offerng Continuous Fluid Bed Dryers with excellent efficiency. The process air is supplied to the bed through a special perforated distributor plate and flows through the bed of solids at a velocity sufficient to support the weight of particles in a fluidized state. Bubbles form and collapse within the fluidized bed of material, promoting intense particle movement. In this state, the solids behave like a free flowing boiling liquid.


* Advanced method of drying wet/semi wet solids
* Unlike in Tray Drying every solid particle is floating in the HOT STREAM of Air which is blown from down to up creating material layer in fluidised state
* Almost every wet particle directly receives the heat energy from hot Air resulting in uniform and quick drying
Features of Continuous Fluid Bed Dryers


* Very versatile process equipment for uniform and efficient drying of products.
* Fully automatic operation based on PLC control / without more...

Tablet Dissolution Tester DR-8 represents the very latest in tablet testing technology. Excellent production techniques combined with modern microprocessor design guarantee the highest standards of performance and reliability. All dissolution testers meets the latest specifications as laid down in the European, United States and associated pharmacopoeia. Efficient, compact and light weight stirrer unit Tablet Dissolution Taster DR-8 is a rugged unit having eight test vessels and one vessel for replenishment medium. simple & easy to use controls. It is ideal for both R&D and routine quality control applications. The design of the unit has based on these features that the user, advised us as being essential to the ideal dissolution tester. DR-8 has been specifically designed to reduce clutter and maximize visibility and access in the critical sampling area above the water bath particular emphasis has been placed on those factors affecting eccentricity, alignment and centering in more...

Vibro separator are circular gyratory screens used to separate mass composition of solids from solids, liquid from solid and for gradation of materials as per particle sizes, having a very wide range of user friendly application.

This is accomplished by vibrating the screens in three different planes along the vertical axis by means of a specially designed vibratory motor having off-centred weights at the top and bottom end of the motor shaft.

The top weight causes vibration in the horizontal plane which causes the material to move across the screen towards the periphery. The lower weight creates vibration in the vertical tangential axis. The angle of lead of the lower weight with relation to the upper weight provides variable control of the screening pattern.

Thus the material moves across the screens and also in the vertical and tangential planes enabling maximum screening.

Vibro sifter are available with a wide range of possible screen more...

Process Controls :
* PLC enables automated process control of the complete manufacturing facility.
* Control panel visually shows all operations of the plant on a mimic display.
* Continuously variable speed control of the mixing arm is achieved by AC frequency controller.
* Digital display of product temperature and current values on the control panel.
* Capacity : 100 kgs. - 5000 kgs.
more...

Range of vibro sifter that we offer is widely demanded in several pharmaceutical, beverage and other products manufacturing industries. These are designed as to separate solid and liquid particles from composition. These are manufactured using high quality of raw material and are supplied in various parts of the world at competitive market prices.

* Meets current specifications of USP, IP, and other Pharmacopoeias
* Offers a count and time mode.
* Automatic discharge of the sample into individual sample tray after completion of each cycle.
* 10o tilting of drums as per USP recommendation.
* Easy front loading system
* Supports friability drum and abrasion drum
* Calculation of friability - percentage weight-loss.
* Balance interface for sample weight transfer.
more...

Product description :

Container of Fluid Bed Dryer is made out of MS / SS304 / SS316 / Aluminium as per requirement. The perforated sheet & fine wire mesh screen will be provided at the bottom for proper air distribution.
HEATING can be supplied with Electrical, Steam, Thermic Fluid or Hot Air Generator.
Electrically heated Dryer will be provided with heating element of suitable rating having MS galvanised / Stainless steel construction. Steam / Thermic Fluid Radiators are made out of MS / SS Tubes with MS / SS / AL Fins as per requirement.
Control panel will consist of Digital Temp. Controller, Starter for Blower, Synchronous Timer for batch time setting, Indicating Lamps, Fuses, Main Isolator switch etc. more...

Fluidized Bed Dryers more...

We are enlisted as one of the leading manufacturers and suppliers of Tablet Hardness Tester Pfizer Type based in India. Clients can avail this machine in different shapes with different precision engineered components such as dial gauge, aluminum body and others. The capacity of this machine is 0 to 20 kgs. It is packed in polished wooden boxes. more...

We offer high quality of Bulk Density Apparatus

We are involved in the manufacturing and supplying of a wide range of GMP Reactors, which are applicable in several chemical and pharmaceutical industries. They are basically used for the applications like production of life saving drugs, food herbal, chemical bulk drugs and ayurvedic medicines, etc. These are developed in accordance with the customers' requirements. They are available with mechanical or electro-polishing, at reasonable prices.

Our fluid Bed is designed to dry products as they float on a cushion of air or gas.These dryers find extensive application in chemical, food, dyestuff, and polymer industries for fast and efficient drying. The contact parts of the dryers are made using SS 304 and 316 grades. Our fluid dryers integrate fully automatic control panel box with process timer, pneumatic lifting of container, digital temperature controller cum indicator, pneumatic finger bag shaking, voltmeter, ammeter and earthing system.

Operation:
* Due to induced draft created by specially designed heavy-duty fan, the atmospheric air is drawn through air filter
* The filtered air is then heated to the required temperature by electric/ steam radiator
* The hot air passes through the product container and the product is dried by air fluidization
* The air circulation is controlled by damper
* The filter bag prevents fine particles from carrying over to exhaust air stream
more...

Vibratory fluid bed dryer for cooling process for salt.

Our capsule hand filling machine 300 Holes, which is easy to operate and finds application in pharmaceutical industry. Precise design of these machines ensures simple operations that give accurate results with negligible rejection. These machines require less maintenance and manufactured using sophisticated technology to ensure durability and high performance at client’s end.   Process:
* Fill loading tray with empty capsule
* Place loading tray on top plate, operate cam handle can be used to separate the cap and body of the capsule
* Place powder tray in position
* Fill accurate quantity of powder dispenser
* Use operate lever to lock the cap and body of capsule
* Remove loading tray and discharge the filled capsules
  Features:
* No deviation and negligible rejection
* Muscular and easy movable
* Excellent cost benefit ratio
* Easy availability of spares
more...

We specialize in manufacturing lab equipment in standard as well as customized specifications to suit diverse requirements of the pharmacology sector. The physiology and engineering equipment conform to highest quality standards and are designed to ensure durability & accurate results. Available at best market prices, we can deliver pharmacology lab equipment in desired quantities across the globe within a set time frame.   Our clients can buy the following equipment::
* Organs Baths
* Kymographs
* Levers.
  more...

Stirrer consists of different types of impeller fixed on a SS shaft and directly coupled to an electric motor. It can be directly mounted on the vessel or can be fixed on a separate movable stand with lowering and lifting arrangement. Fixed RPM or with variable AC frequency drive or with geared motor. Capacity: 0.25 HP to 15 HP (Standard and GMP model) with SS 304 or SS 316 contact parts.
